GRX 5100: EV/HEV Battery Service Tool
The industry’s first and most fully-featured high-voltage EV/HEV battery service tool, the GRX-5100 performs full battery pack service for hybrid and electric vehicles.
GRX 5100 Features
- Software updatable via USB interface
- 0 – 384 VDC compliant
- Reverse polarity protected
- Hard safety disconnect
- Redundant systems monitoring, including battery module temperature
- 1. Throttles back current upon excessive temperature rise or restricted air flow
- 2. Terminates session when reaching temperature limit
- Monitors high-voltage leakage to chassis
- 1. Terminates session upon excessive leakage
GRX 5100 Specifications
- AC Main Power: 100-240 VAC 50/60 Hz, 12A max, continuously monitored for maximum charge rate, > 0.95 PFC, 89% efficiency
- Discharger: 0-7.5 Amperes DC
- Charger: 0-5.0 Amperes DC
- Input / Output: Independent CAN BUS (2), LIN (1), Digital I/O (8)
- Dimensions & Weight: 13 In H X 29 In W X 17 In D
- Weight: 24.04 Kg (Including Accessories/Cables: 34.02 Kg
